Yarn
Knitted UV-stabilised HDPE
-
Construction
Monofilament & tape
-
Pattern
Lock-stitch knitted
-
Temperature range (°C)
-30 to +70
-
Roll length (m)
40
-
Roll width (m)
3.00 (folded)
-
Nominal fabric mass (gsm) (AS 2001.2.13)
340 +/- 30
-
Approximate thickness (mm)
~1.6
-
Tensile strength – warp (N/50mm) (AS 2001.2.3.1)
670 N/50mm
-
Elongation at break – warp (%) (AS2001.2.3.2)
117%
-
Tensile strength – weft (N/50mm) (AS 2001.2.3.1)
2400 N/50mm
-
Elongation at break – weft (%) (AS2001.2.3.2)
83%
-
Wing tear – warp (mean) (AS2001.2.10)
184 N
-
Wing tear – weft (mean) (AS2001.2.10)
347 N
-
Burst pressure (kPa) (AS4878.5 – Method B)
3500 kPa
-
Burst force (N) (AS2001.2.19)
1937 N
-
Flammability Index (range0-100)
12
-
Lead
Not detected
-
Pthalate
Not detected
